Introduction to MDD115D-N-020-N2M-130-PA2 Motor

I. General Overview

The MDD115D-N-020-N2M-130-PA2 is a high-performance synchronous servo motor produced by Bosch Rexroth, belonging to the IndraDyn S series. This motor is widely used in industrial automation due to its high torque, high speed, high precision, and excellent environmental adaptability.

II. Key Features

1. High Torque Output:
   • The maximum torque can reach 631Nm, meeting the needs of various high-load applications.
   • Smooth torque output with minimal fluctuations ensures stable equipment operation.
2. Wide Speed Range:
   • The maximum speed can reach 9000rpm, suitable for applications requiring high-speed operation.
   • A wide speed adjustment range allows for flexible adjustments based on actual needs.
3. High-Precision Control:
   • Equipped with a multi-turn absolute Hiperface encoder with an increment of 128, providing high-precision position feedback.
   • High encoder resolution ensures precise and stable motor movement.
4. Excellent Environmental Adaptability:
   • High protection class, typically IP65 or above, enabling stable operation in harsh environments.
   • Optional liquid cooling system available to handle heat dissipation in high-power applications.
5. Compact Structure:
   • The motor is designed to be compact, with a small size and light weight, facilitating easy installation and maintenance.
   • Flat shaft design with shaft sealing rings prevents dust and moisture from entering the motor interior.

III. Application Scenarios

The MDD115D-N-020-N2M-130-PA2 motor is widely used in various industrial automation fields requiring high precision and high torque, including but not limited to:

1. Robot Arms:
   • Provides high torque and precise position control, ensuring flexible movement and accurate positioning of robot arms.
2. Automated Production Lines:
   • Used to drive various automated equipment, such as conveyors and assembly machines, improving production efficiency and product quality.
3. Packaging Machinery:
   • Suitable for high-speed packaging machinery, such as filling machines and sealing machines, ensuring stable and accurate packaging processes.
4. Conveyor Systems:
   • Used to drive conveyor belts, rollers, and other conveying equipment, enabling fast and accurate material transportation.

IV. Technical Parameters

• Rated Power: Varies depending on the specific model and application scenario, but typically meets the needs of high-load applications.
• Rated Voltage: Usually an AC voltage, with the specific value determined by the motor model and配套 (matching) drive.
• Rated Current: Determined based on the motor power and voltage, ensuring stable motor operation under rated conditions.
• Encoder Type: Multi-turn absolute Hiperface encoder, providing high-precision position feedback.
• Protection Class: Typically IP65 or above, ensuring stable motor operation in harsh environments.
• Cooling Method: Natural convection cooling or optional liquid cooling system, selected based on application scenario and power requirements.

This introduction provides a comprehensive overview of the MDD115D-N-020-N2M-130-PA2 motor, highlighting its key features, application scenarios, and technical parameters.
