Name: 330130-085-00-00 BENTLY TSI system module - Saul Electric
Brand: Bently Nevada

Description

330130-085-00-00 BENTLY TSI system module

330130-085-00-00 Product Introduction

BENTLY 330130-085-00-00 gateway is designed with multi protocol compatibility and modularity, seamlessly connecting industrial systems,
operating at a wide temperature range of -40 ° C to 85 ° C, supporting 8-channel rotating equipment monitoring,
remote configuration to improve efficiency, and ensuring stable power and automation.

1、 Product Overview

BENTLY 330130-085-00-00 is part of the Bently Nevada 3500 series monitoring system and is a communication gateway module designed specifically for industrial automation and process control applications.
It can connect the Bently Nevada 3500 system with other control systems or host computers to achieve data interconnectivity.

2、 Main characteristics

Communication interface: This module has rich communication interfaces and supports multiple communication protocols such as Ethernet, RS232, RS485, etc. It can be compatible with protocols such as Modbus and TCP/IP,
thus achieving integration with other industrial control systems.

input/output signal

Input signal: 0-10V DC, 4-20mA DC.

Output signal: 0-10V DC, 4-20mA DC.

Channel Count: Provides 8 analog input and 8 analog output channels to meet various monitoring and control requirements.

Working parameters:

Working voltage: 24VDC.

Working temperature range: -40 ° C to+85 ° C (some sources mention -30 ° C to+65 ° C or -40 ° C to+70 ° C, depending on the application environment).

Working humidity: 0% to 95%.

Remote configuration and management: Supports remote configuration and management functions, allowing for remote system settings and monitoring through the network, improving operational efficiency.

Modular design: Adopting a modular design, it is easy to install and maintain, reducing system downtime and maintenance costs.

High reliability and stability: After rigorous testing and validation, it ensures stable performance in various harsh environments, suitable for multiple fields such as industrial automation, process control, mechanical vibration monitoring and protection.
